Brake pressure air switch M12x1,5, switching pressure: 2,7 bar
40,50 € excl. VAT
Brake pressure air switch M12x1,5, switching pressure: 2,7 bar
679 011 1013
We deliver customized solutions!
Brake pressure switches are used in vehicles and machines to close or open a contact when a defined pressure is exceeded. Suitable media are air, oil or water.
MOTOMETER brake pressure switches are available in different versions.
Operation is possible with 12 Volt or 24 Volt on-board supply system. Depending on the version, the switching point is between 0.5 bar and 9 bar.
Design variants
679 001 xxxx opens when the pressure is exceeded
679 011 xxxx opens when the pressure is exceeded
Available only mass-free
679 002 xxxx closes when the pressure is exceeded
679 012 xxxx closes when the pressure is exceeded
679 016 xxxx closes when the pressure is exceeded
| Weight | 0,103 kg |
|---|
Brake pressure air switch
Rated voltage: 24V
Switching point: 2,7 bar at 20°C
Max. continuous load: 10bar compressed air
Further details: see drawing
