Fuel Level Sensor, reed type, l=602mm, d=54mm
219,60 €
Fuel Level Sensor, reed type, l=602mm, d=54mm, 608 020 1065
Discover our high-quality Fuel Level Sensors with reed contact – the perfect solution for vehicle tanks with a depth of up to 1300 mm. Specifically designed for longer lengths exceeding 600 mm, these sturdy dip tube senders provide reliable performance, even under the influence of slosh forces.
Reed sensors with an empty value of 60-90 Ohm are compatible with these MOTOMETER display
instruments:
609 004 xxxx
609 005 xxxx
609 004 xxxx
609 005 xxxx
609 104 xxxx
Can be extended to 80 mm diameter using our MOTOMETER adapter flange:
608 044 0000
608 044 0000
| Weight | 0,428 kg |
|---|
Pitch circle diameter: 54 mm Length: 602 mm Nominal load: Pmax = 300 mW Operating temperature: -40 … +85° (max. 95°C max 1h) Suitable for: Diesel (DIN EN 590), winter diesel, RME (DIN V 51606) With additives from: Petrol, kerosene, methanol, ethanol Marking: Part number, date of manufacture, MM logo Material: Stainless steel 1.4401 Electrical connection: Lug A 6.3 x 0.8 DIN 46244 with hexagon nut Installation diameter: 43+-1mm Accessories: Rubber seal Remark: Reed Art. No.: 608 020 1065
Special wishes?
We deliver customized solutions!
In addition to the standard sensor listed, we can also offer you customized, specific solutions. Simply contact us with your requirements via the contact form:
